Biological microscope for professional use, equipped with improved Koehler lighting system that allows observing clear and bright images under each magnification. Used for clinical diagnosis, experimentation for higher teaching and pathological tests.
High and steady structure, fully metallized at high pressure and supports Allen key on the upper left side. Provides optional configurations for various applications.
Specifications
| Eyepiece: PL 10X/22 mm |
| Nosepiece: Quintuple |
| Objectives: 4X, 10X, 40X (S),100X (S) (oil) |
| Optical system: Infinity-corrected plan achromatic |
| Stage: Double layer with coaxial movement X-Y, 175 x 145 mm / 6.8" x 5.7" |
| Condenser: Achromatic swing-ouy condenser Abbe, N.A. 1.2/0.22 Equiooed with adapter bracket for aditional configurations (not included) |
| Diaphragm: Iris type with filter holder. |
| Focus: Coarse and fine anti-slip control knob (precision 0.001 mm) |
| Ilumination: Kohler Halogen 6V/30W |
| Power supply: 110/240V, 50/60 Hz, AC Adapter. |
| Dimensions: 463 x 408 x 250 mm / 18.2" x 16" x 9.8" |
